Introduction
Sankalp Alloys Overseas is one of the renowned ISO 9001:2000 manufacturers, suppliers, stockists, and exporters of Incoloy 800 Flanges in India and global markets. Available in various sizes, shapes, thicknesses, and dimensions as per customer requirements, our flanges fit into diverse domestic and international industrial setups.
As leading Incoloy 800 Flanges Manufacturers in India, Incoloy 800 Flanges Suppliers in India, and Incoloy 800 Flanges Exporters in India, we ensure that every product crafted in our facility conforms to strict quality parameters. Based out of the primary industrial hub, we are also trusted as Incoloy 800 Flanges Manufacturers in Mumbai, Suppliers in Mumbai, Stockists in Mumbai, and Exporters in Mumbai.
Backed by an ultra-modern manufacturing unit, our team of experienced professionals produces top-notch forged flanges. We use superior quality raw materials that are rigorously tested using the latest machinery and methodologies to assure flawless, long-lasting performance at highly competitive prices.
What are Incoloy 800 Flanges?
Incoloy 800 (UNS N08800 / W.Nr. 1.4876) is an iron-chromium-nickel alloy engineered for high tensile strength and outstanding resistance to elevated temperatures. The high nickel content provides exceptional protection against chloride pitting and stress corrosion cracking (SCC), making it an ideal choice for high-stress industrial applications.
For more severe environmental demands, improved versions such as Incoloy 800H (UNS N08810) and Incoloy 800HT (UNS N08811) offer enhanced creep rupture and stress rupture strengths. Whether for critical high-temperature thermal processing units or standard fluid transfer piping, Sankalp Alloys Overseas is your go-to solution provider for premium Inconel N08800 Flanges.
Types of Incoloy 800 Flanges We Supply
We manufacture and export a wide spectrum of ASTM B564 Incoloy 800 Forged Flanges to meet custom process requirements:
- Inconel N08800 Slip On Flanges: Easy to align and slide over the pipe, widely used for moderate pressure systems.
- Incoloy 800 Weld Neck Flanges: Designed to transfer stress to the pipe, offering excellent structural reinforcement in high-pressure setups.
- ANSI B16.47 Incoloy 800 Blind Flanges: Used to block/seal the end of piping systems or pressure vessel openings securely.
- Inconel N08800 Socket Weld Flanges: Ideal for small-diameter, high-pressure piping applications.
- Incoloy 800 Lap Joint Flanges: Preferred in systems requiring frequent dismantling for inspection and cleaning.
- Incoloy 800 Threaded Flanges: Screwed onto pipes without welding, ideal for low-pressure gas or fluid pipelines.
- Incoloy 800 Forged Flanges & Plate Flanges: Heavy-duty DIN 2.4876 ASTM B564 Plate Flanges engineered for extreme operational stress.
Incoloy 800 Flanges Specification
Detailed technical specifications for our range of Incoloy 800 Flanges:
| Parameter | Details |
|---|---|
| Standard | ASTM, ASME, ANSI, JIS, DIN, BSNA 11, EN Ni 99.2, JIS NW 2200, GOST-НП-2 |
| Dimensions | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Designation | ASTM / ASME B 564 / SB 564 |
| Class | Class 150, Class 300, Class 400, Class 600, Class 900, Class 1500 & Class 2500 |
| Size | 1/2" NB TO 60" NB |
| Grades | Incoloy 800 (UNS N08800) Flanges, 2.4876 |
| Pressure | DIN PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160 |
Incoloy 800 Flanges Equivalent Grades
Check the global standard cross-reference chart for Incoloy 800, 800H, and 800HT:
| Standard | Incoloy 800 | Incoloy 800H | Incoloy 800HT |
|---|---|---|---|
| UNS | N08800 | N08810 | N08811 |
| WERKSTOFF NR. | 1.4876 | 1.4958 / 1.4876 | 1.4859 / 1.4876 |
| AFNOR | Z8NC32-21 | Z8NC33-21 | - |
| JIS | NCF 800 | NCF 800H | NCF 800HT |
| GOST | ЭИ670 | ЭИ670 | ЭИ670 |
| BS | NA 15 | NA 15(H) | NA 15(HT) |
| EN | X10NiCrAlTi32-20 | X5NiCrAlTi31-20 | X8NiCrAlTi32-21 |
| OR | XH32T | XH32T | XH32T |
Incoloy 800 Flanges Chemical Composition
Chemical element percentage matrix across 800, 800H, and 800HT variants:
| Element | 800 | 800H | 800HT |
|---|---|---|---|
| Ni | 30-35 | 30-35 | 30-35 |
| Fe | 39.5 min | 39.5 min | 39.5 min |
| Cr | 19-23 | 19-23 | 19-23 |
| Cu | 0.75 max | 0.75 max | 0.75 max |
| Ti | 0.15-0.60 | 0.15-0.60 | 0.25-0.60 |
| Al | 0.15-0.60 | 0.15-0.60 | 0.85-1.20 |
| C | 0.1 max | 0.05-0.1 | 0.06-0.1 |
| Mn | 1.5 max | 1.5 max | 1.5 max |
| S | 0.015 max | 0.015 max | 0.015 max |
| Si | 1.0 max | 1.0 max | 1.0 max |
Incoloy 800 Flanges Mechanical & Physical Properties
Physical parameters and strength thresholds for UNS N08800 flanges:
| Property | Value |
|---|---|
| Density | 7.94 g/cm3 |
| Melting Point | 1385 °C (2525 °F) |
| Tensile Strength | Psi - 75,000 , MPa - 520 |
| Yield Strength (0.2% Offset) | Psi - 30,000 , MPa - 205 |
| Elongation | 30 % |
Applications of Incoloy 800 Flanges
Chemical and Petrochemical Plants
Extensively used in process equipment, ethylene furnace quenching systems, nitric acid management, and high-pressure chemical transport.
Power Generation & Nuclear Industry
Installed in superheaters, reheaters, and steam generator tubing systems in power stations due to superior high-temperature stability.
Heat-Treating Equipment
Ideal for radiant tubes, retorts, muffles, and heat treatment furnace equipment operating under continuous high thermal loads.
Refineries & Oil Processing
Applied in catalyst recovery units, hydro-cracking processes, and gas processing lines needing high resistance to chloride pitting and oxidation.
Why Choose Sankalp Alloys Overseas?
Sankalp Alloys Overseas stands out as a premier global partner for high-nickel alloy piping solutions:
- ISO 9001:2000 Certified Quality: Continuous upgrading and stringent quality control in every process assure error-free manufacturing.
- State-of-the-Art Unit: Equipped with advanced forging, machining, and testing facilities to deliver custom dimensions efficiently.
- Global Supply Chain: Prompt delivery and reliable supply network serving major industrial regions across India and worldwide.
- Competitive Pricing: Direct-from-factory pricing paired with uncompromised metallurgical standards.
Frequently Asked Questions (FAQs)
Q: What types of Incoloy 800 Flanges do you supply?
A: We supply Incoloy 800 Slip-on flanges, weld neck flanges, blind flanges, socket weld flanges, threaded flanges, lap joint flanges, and long weld neck flanges.
Q: Do you supply Incoloy 800 Flanges in Mumbai and across India?
A: Yes, Sankalp Alloys Overseas is a major manufacturer, supplier, stockist, and exporter of Incoloy 800 Flanges in Mumbai, across India, and to international destinations globally.
Q: Are Material Test Certificates provided with shipments?
A: Yes, all shipments are accompanied by official EN 10204 3.1 Material Test Certificates, chemical analysis, and non-destructive testing reports.
Q: What pressure classes are available?
A: We supply ANSI classes 150# through 2500# and DIN ratings from PN6 up to PN160.
Conclusion
Incoloy 800 Flanges offer unmatched heat resistance, mechanical strength, and protection against corrosion in critical industrial applications. Whether you need standard ASME B16.5 flanges or custom forged components, Sankalp Alloys Overseas is your trusted ISO 9001:2000 certified manufacturing and exporting partner.
Contact Sankalp Alloys Overseas today for flawless quality, prompt delivery, and competitive pricing on all your Incoloy 800 Flange orders.
